    TSTS-6060 1000 Kg Payload Capacity Pneumatic Shock Test Machine

    TSTS-6060 1000 Kg Payload Capacity Pneumatic Shock Test Machine

    1000000-10000000 INR/Piece

    Product Details:

    X

    TSTS-6060 1000 Kg Payload Capacity Pneumatic Shock Test Machine Price And Quantity

    • 1000000-10000000 INR/Piece
    • 1 Piece

    TSTS-6060 1000 Kg Payload Capacity Pneumatic Shock Test Machine Trade Information

    • 10 Piece Per Month
    • 3 Months

    Product Description

    Specification

    Model

    TSTS - 6060

    Table Size

    600 x 600 mm

    Payload Capacity

    200 Kg

    Payload Height

    unlimited

    Max Payload Size

    600 x 600 mm

    Insert Pattern

    100 x 100 mm Matrix

    Stroke Length (Max)

    300 mm

    Velocity Change No load

    7 m/s

    Velocity Change Full Load

    5 m/s

    Standard Test*

    20g 11ms
    30g 20ms
    40g 6ms
    50g 11ms
    50g 18ms
    100g 6ms
    150g 3ms
    200g 3ms



    Pulse Shape

    Half Sine Optional - Sawtooth / Square wave / Trapezoidal Waveform

    Shock Rate

    1-8 shocks/min

    Max Deviation of specimen from table centre

    30 mm

    Machine Mass

    4000 kg

    Dimensions (mm)

    900*900*1500

    Utilities required

    Plant air or bottled Nitrogen 6-8 bar 410V, 3 -phase 50 Hz

    Safety Interlocks

    Mains Input Over & Under Voltage, Phase drop, programmer pad change protection, over travel, Fail safe brake
